Staple Making Machine Specification
Machine Type	Staple Type	Configuration Parameter	Leg length	Power	Strips/Min
Brads machine-brads not with flat head	F/ FT/ TN		Length of F brads: 12, 15, 16, 19, 20, 25,30, 35, 40, 45, 50mm Length of FT brads:20,25,32,38,45,50mm Length of TN:25,32,38,44,50,55,62mm	7.5KW	100-150
Brads machine-brad with flat head	F/ FT/ TN		Length of F brads: 12, 15, 16, 19, 20, 25,30, 35, 40, 45, 50mm Length of FT brads:20,25,32,38,45,50mm Length of TN:25,32,38,44,50,55,62mm	7.5KW	100-110
Hydraulic Fine Wire Staple Machine	380/71/A11	1. With NCRF feeding system(servo feeder); 2. Including the punching machines and packing machine; 3. Including leveling machine	Length of staples: 3mm~20mm	7.5KW	150-160
Hydraulic Heavy Wire Staple Machine	90/92/16/14/180 STAPLES	1. With NCRF feeding system(servo feeder); 2. Including the punching machines and packing machine; 3. Including leveling machine	Length of staples: 15mm-50mm	7.5 KW	80-100
Hydraulic Heavy Wire Staple Machine	180/55-180/75 STAPLES		Length of staples: 55mm-80mm(These big leg lengths need hard material)	7.5 KW	80-90
Carton Closing Staple Machine	32/35 CARTON CLOSING STAPLES		Length of staples: 12,15,16,18,19,22mm	7.5 KW	80-100

We can supply professional technical guidance for free all time
